Highway Guardrail Roll Forming Machine,Crash Barrier Roll Forming Machine
產品型號：MXM1701
產品分類：自動化設備/產業機械 / 其他產業機械 / 建材機械
產品特色
Technical Data of highway guardrail forming machine:
Manual Uncoiler
Loading Weight: 5 Max.
Inner diameter of coil: 508mm.
Maximum diameter of coil: 1500mm
Thickness of Material: 2-3mm.
Levelling machine before highway guardrail forming machine:
7-roller levelling
Dia. Of Roller: 70mm.
Material of Roll: 40Cr quenched into HRC48~52 degrees.
Punching machine before highway guardrail forming machine:
Using type Yl32-315 hydraulic puching machine with 4 pillars.
Hydraulic pressure power: 11kw
Material of blade: Cr12MOV
Highway guardrail forming machine: :
Construction Structure: 36# "H" welded steel.
Forming Station: 14 stations.
Forming Speed: 8_15m/min.
Material of Roller: GCr15 steel with tempering and quenching treatment.
Dia. Of Shafts: 90mm.
Transimission of Machine: By 1.5" chain-brackets or by gear boxes.
Power of Main Machine: 18.5kw.
Material of Shaft: 40Cr steel with high-frequency quenching treatment.
Dimmension of main machine: 8600mmx1500mmx1900mm
Weight: 12 Tons.
Hdraulic Cutting device after highway guardrail forming machine:
Material of cutter blade: Cr12MOV steel with quenched treatment.
Cutting system: Adopt advanced hydraulic drive, automatic cut after forming
Panasonic PLC Control, LCD screen, touch screen, frequency converter
Voltage: 380V/50Hz/3phase
Remarks: We can produce both chaini-gear transmission and gear-boxes transmission;we can produce both 2 wave crash barriers and 3 wave crash barrier; we can produce the crash barrier roll forming machine which can handlel with material up to 5mm thickness.
Contact Person:Tony Tang
Cell:+86-18001958638
Email: [email protected]
MSN: [email protected]
Skype: tangleitony
Website: http://www.mtc-china.com
OR: http://www.coldrollformer.com
產品規格
Technical Data of highway guardrail forming machine:
Manual Uncoiler
Loading Weight: 5 Max.
Inner diameter of coil: 508mm.
Maximum diameter of coil: 1500mm
Thickness of Material: 2-3mm.
Levelling machine before highway guardrail forming machine:
7-roller levelling
Dia. Of Roller: 70mm.
Material of Roll: 40Cr quenched into HRC48~52 degrees.
Punching machine before highway guardrail forming machine:
Using type Yl32-315 hydraulic puching machine with 4 pillars.
Hydraulic pressure power: 11kw
Material of blade: Cr12MOV
Highway guardrail forming machine: :
Construction Structure: 36# "H" welded steel.
Forming Station: 14 stations.
Forming Speed: 8_15m/min.
Material of Roller: GCr15 steel with tempering and quenching treatment.
Dia. Of Shafts: 90mm.
Transimission of Machine: By 1.5" chain-brackets or by gear boxes.
Power of Main Machine: 18.5kw.
Material of Shaft: 40Cr steel with high-frequency quenching treatment.
Dimmension of main machine: 8600mmx1500mmx1900mm
Weight: 12 Tons.
Hdraulic Cutting device after highway guardrail forming machine:
Material of cutter blade: Cr12MOV steel with quenched treatment.
Cutting system: Adopt advanced hydraulic drive, automatic cut after forming
Panasonic PLC Control, LCD screen, touch screen, frequency converter
Voltage: 380V/50Hz/3phase
Remarks: We can produce both chaini-gear transmission and gear-boxes transmission;we can produce both 2 wave crash barriers and 3 wave crash barrier; we can produce the crash barrier roll forming machine which can handlel with material up to 5mm thickness.
Contact Person:Tony Tang
Cell:+86-18001958638
Email: [email protected]
MSN: [email protected]
Skype: tangleitony
Website: http://www.mtc-china.com
OR: http://www.coldrollformer.com
