Standing Seam Roll Former,BEMO Sheet Roll Forming Machine by Shanghai MTC



產品型號：MXM1301

產品分類：自動化設備/產業機械 / 其他產業機械 / 建材機械



立即線上詢問





產品特色



Work Flowing OF bemo sheet roll forming machine:
Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

Technical Data for bemo sheet roll forming machine line:
Decoiler
Decoiler Type: Manual Decoiler manual expansing, passive uncoil
Weight Capacity Of Decoiler: 5 Ton

Bemo sheet roll forming machine:
Raw Material: Color steel, GI coil
Raw Material Thickness: 0.3-0.8mm
Speed: 10-15 m/min
Main Motor Power: 5.5 KW
Roller Stands: 16 Groups
Machine Frame stand: Welded structural steel
Thickmess of Fame Steel: 16mm
Material of Roller: 45# steel, coated with hard chrome 0.05mm chrome.
Transporting Type: Chain Transmission
Material Of Chain: High Grade 45#, Heated and quenched HRC 45-50
Main Axis Material: High grade 45#
Axis Diameter: 70mm
Voltage: 380V, 3 Phase 50Hz ( or according to customers local requirement )
Machine Weight: 5.6 Ton
Bemo sheet roll forming machine Dimension: About 9000mm(L) x 1400mm(W) x 1300mm(H)

Cutting Device & Hydraulic Station of bemo sheet roll forming machine line:
Type of Cutting: Hydraulic cutting
Material Of Blade: Cr 12
Cutting Tolerance: +/-2mm
Heat Treatment of Cutting Blade: HRC 50-60
Hydraulic Motor Power: 3 Kw

Electrical System of bemo sheet roll forming machine:
Electrical Control: PLC Frequency Control System with touch screen
PLC Brand: Japnese Panasonic Brand
Encoder Frequency Control System: Omron Brand
Transducer: ABB
Size of PLC Control Board: 700mm(L)x1000mm(H)x300mm(W)
Electrical control system: Japanese Panasonic PLC Board
