產品規格



Nominal force KN 300
Stroke under nominal force mm 5
Slide block stroke mm 75
Number of stroke min-1 75
Max. die set height mm 180
Die set height adjustment mm 50
Distance from slide block centre to the frame mm 170
Worktable dimensions (W x L) mm 320x500
Thickness of bolster mm 70
Size of side block bottom surface (W x L) mm 160x200
Size of the handle hole (Diameter x Depth) mm φ40x 50
Max. tilting angle of body º 25 º
Motor Power KW 3
Machine weight Kg 1500
