產品規格



Specification/Model Unit DW38NC
Max bending capability mm Φ38×2
Max bending radius mm R260
Min bending radius mm R15
Max bending angle Degree 190
Max effective distance of mandrel mm 1600
Control System 　 NC Control
Max elbow bend pipe Unit 16
Max storable sections Unit 16×16
Motor power KW 4
Max. Hydraulic Pressure Mpa 12
Hydraulic System Control 　 Electromagnetic Valve
Oil Tank Capacity L 110
Measurement mm 2600×600×1000
Weight of Machine Kg 750
