產品規格



Max. bending diameter x wall thickness mm Φ75×2
Maximum bend radius mm R400
Minimum bend radius mm R15
Maximum bending angle Degree 190
Standard wear core length mm 2800
Control system Mircosoft pc control
Bend number one pipe Unit 16
Store parts numeber Unit 16×16
Motor power of oil pressure KW 7.5
Maximum system pressure Mpa 12
Hydraulic system control Solenoid valve
Tank capacity L 250
Size mm 4000×1000×1100
Weight Kg 2000
