120L-220L PC gallon blow molding machine-KINGSWEL GROUP
產品型號:HC PC special PC gallon molding machine
產品分類:自動化設備/產業機械 / 自動化設備 / 自動化機械,氣壓式
產品特色
Technical data and parts instructions of blow molding machine for series of HC90
HC90
Max. volume of products(L) 120
Material PC
Screw diameter(mm) φ90
L/D 28:1
Die head(single layer accumulator with servo parison control 8L
Dia. Mouth 300MM
100 Point
25KW
Plasticizing capacity(kg/h) 140
Platen dimension(W×H)(mm) 1050*1000
Platen opening stroke
(mm) Idler wheel type 5500∼11400
Guide way type 450∼1100
Max. speed of clamping device PC/H 600(idle cycle)
Mould dimension(W×H)(mm) 700×1000
Mould thickness(mm) 405∼600
Max clamping force(KN) 270
Accumulator volume(L) 6(8L optional)
Max diameter of die(mm) 350
Parison control servo system Pressure 16 Mpa
rate flow 23 L / min.
Bom power 4kw
Hydraulic system pressure(Mpa) Small pump 18
Big pump 12
Heating power of die(kW) 20
Heating power of extrusion(kW) 25
Motor power of oil pump(kW) 30
Pressure air (Mpa) 0.8-1
air consumption M3 / Min. 0.4-1
Pressure for cooling 0.3
Motor power of parison thickness(kW) 4
Driving power(kW) 45
total power(kW) 129
Average consumption(kW/h) 50
Machine weight(T) 16
Machine dimension(LxWxH)m 5.7x3.1x4.7
產品規格
Mr Aladdin Âu
China head office +86 - 15895594220
Viet Nam office +84 - 0975118000
Y! Messager / MSN Live: auvuchi
Skype: kingswelgroup QQ: 1123006779
Video: http://www.youtube.com/kingswelgroup
Tel: +86-512-58674468/58698355
Fax: +86-512-58698356
Website: www.kingswel.com
Email: [email protected] , [email protected]
Zhangjiagang HuaFeng Heavy Duty Equipment Mfg. Co., Ltd.
Zhangjiagang Kingswel Machinery Exp. & Imp. Co.,Ltd.
Address: Zhangjiagang Economical Development Zone, Zhangjiagang, Jiangsu, China
Zhangjiagang Huafeng Heavy-Duty Equipment Manufacturing Co., Ltd. is one of the biggest production bases of blow molding machinery in the world. Our company is specialized in designing, manufacturing and selling all types of blow molding devices which are suitable for manufacturing hollow plastic products such as plastic bottles, pots, barrels, boxes, bags, toys, plastic trays, and super-big plastic barrels with the occupation of 0.01-5000 liters. The biggest 1000-liter hollow blow-molding machine is right here. With 60% of market share, various kinds of products have been sold to Southeast Asia, Europe, America, and Arabia. All the components of our products have passed the certifications of American UL, CSA and ISO9000:2000, which ensures our products of the highest quality. We insist on our belief, with all strength to do the first class design for various kinds of guaranteed quality products, perfect relationship, and our adaptability to times. What we are concentrating on is mechanic design and function. We also try our best to scientifically combine the spirit of your company. Every product is estimated by designers. We have a professional research and study department and offer services around our country. With advanced equipment and personnel, we can grasp chances at any time and quickly provide the best service for you.
