Chain welding Machine
產品型號：CE01W-75
產品分類：自動化設備/產業機械 / 自動化設備 / 自動化焊接設備
產品特色
Automatic Chain welding Machine, The application are lifting round chain welding, also many kinds of round chain such as snow chain, decorated chain, lashing chain, mining chain.
We also supply chain bending machine, chain calibration machine, chain tensile test machine and chain heat treatment machine etc. as a one-stop service for our customers.
產品規格
Technical Data:
|
No. |
Item |
Specification |
|
1 |
Wire diameter |
4-7mm |
|
2 |
Pitch of link chain |
11-30mm |
|
3 |
Output, chain links |
45-50pcs/min |
|
4 |
Rated load succession rate |
20% |
|
5 |
Transformer Power |
75KVA |
|
6 |
Motor Power |
3KW |
|
7 |
Rated speed |
852-1704 |
|
8 |
Rotary encoder |
600 rpm |
|
9 |
Secondary no load voltage |
4-10v |
|
10 |
Pressure of cooling water |
0.15-0.3MPa |
|
11 |
Cooling water |
20 liters/min. |
|
12 |
Cooling water temperature |
15-25C |
|
13 |
Air Supply Pressure |
0.65Mpa min. |
|
14 |
Pneumatic working pressure |
0.45-0.65MPa |
|
15 |
Air consumption |
5 liters/working cycle |
|
16 |
Power |
80 KW |
|
17 |
Size |
1.8X0.95X1.5m |
|
18 |
Weight |
2MT |
Hangzhou Polywin Machinery Co., Ltd. www.polywincn.com is located in Hangzhou City, China and specializes in manufacturing and exporting chain manufacturing series machinery， such as Automatic Chain Bending Machine, Automatic Chain Welding Machine, Automatic Chain Calibration Machine, Automatic Chain Proof Testing Machine, Automatic Chain Cutting Machine, Automatic Chain Marking Machine, Automatic Chain Bend Test machine, Chain Twisting Machine , Tire Chain Making Machines, Chain Heat Treatment Machine etc..
