Automatic Chain Proof Testing Machine
產品型號：CETT-10
產品分類：自動化設備/產業機械 / 檢測設備 / 檢測、量測設備及其另件
產品特色
Automatic Chain Proof Testing Machine, manufacturing proof force testing
產品規格
|
model parameters |
CETT-10 |
|
|
Size range (mm) |
¢4-10mm |
|
|
Max single stroke length (M) |
6.0 |
|
|
Control methods |
PLC+RS485+Frequency conversion servo program control |
|
|
Max tension value (mm) |
220 |
|
|
System max thrust (KN) |
220 |
|
|
System working force(KN) |
110 |
|
|
Motor power(KW) |
6.0 |
|
|
Fastest speed of single stroke |
35S/6 M |
|
|
Air pressure (Mpa) |
≥0.4 |
|
|
Min setting number of links |
>4 |
|
|
PLC Failure alarm setting value |
>10% |
|
|
Sampling voltage |
DC24V/4-20mA |
|
|
Dimension (LxWxH : M) |
8.5×1.0×1.8 |
|
|
Weight (T) |
1.5 |
|
Hangzhou Polywin Machinery Co., Ltd. www.polywincn.com is located in Hangzhou City, China and specializes in manufacturing and exporting chain manufacturing series machinery， such as Automatic Chain Bending Machine, Automatic Chain Welding Machine, Automatic Chain Calibration Machine, Automatic Chain Proof Testing Machine, Automatic Chain Cutting Machine, Automatic Chain Marking Machine, Automatic Chain Bend Test machine, Chain Twisting Machine , Tire Chain Making Machines, Chain Heat Treatment Machine etc..
