產品規格

• Model : PHT - 0813
• Tire type : Scooter tire
• Applicable tire size : 8”~ 13”
• Layer of bias : 2 Ply / 3 Ply / 4 Ply
• Bias width : Max. 570 mm
• Dia. of bias drum : Max. 470 mm
• Lining cloth width : Max. 670 mm
• Dia. of lining cloth drum : Max. 280 mm
• Rotation rate of drum : Min. 50 RPM ~ Max. 220 RPM ( Adjusting by timer)
• Speed of under stitcher : 5 ~ 40 mm / 1 Revolution of drum (Adjusting by timer)
• Main spindle motor : 3 HP x 6 P Induction motor with 5 HP motor drive
• Under stitcher motor : 1/2 HP x 4P x 1/5 Gear reducer with 1 HP motor drive
• Bias servicer motor : 0.5 HP x 4P x 1/15 Gear reducer
• Compressed air pressure : 10 ~ 12 kgf/cm2
• Overall dimensions : L 2600 x W 2230 x H 2000 mm
• Machine net weight : Main machine 1265 kgs, Bias servicer 710 kgs
• Tire building rate : 2 Ply : 580 pcs / 8 hrs, 4 Ply : 420 pcs / 8 hrs

• Model : PHT - 1317
• Tire type : Motorcycle tire
• Applicable tire size : 13” ~ 17”
• Layer of bias : 2 Ply / 3 Ply / 4 Ply
• Bias width : Max. 570 mm
• Dia. of bias drum : Max. 470 mm
• Lining cloth width : Max. 670 mm
• Dia. of lining cloth drum : Max. 280 mm
• Rotation rate of drum : Min. 50 RPM ~ Max. 220 RPM ( Adjusting by timer)
• Speed of under stitcher : 5 ~ 40 mm / 1 Revolution of drum (Adjusting by timer)
• Main spindle motor : 3 HP x 6 P Induction motor with 5 HP motor drive
• Under stitcher motor : 1/2 HP x 4P x 1/5 Gear reducer with 1 HP motor drive
• Bias servicer motor : 0.5 HP x 4P x 1/15 Gear reducer
• Compressed air pressure : 8 ~ 12 kgf/cm2
• Overall dimensions : L 2600 x W 2230 x H 2000 mm
• Machine net weight : Main machine 1265 kgs, Bias servicer 710 kgs
• Tire building rate : 2 Ply : 420 pcs / 8 hrs, 4 Ply : 320 pcs / 8 hrs

• Model : PHT - 1621
• Tire type : Motorcycle tire
• Applicable tire size : 16” ~ 21”
• Layer of bias : 2 Ply / 3 Ply / 4 Ply
• Bias width : Max. 570 mm
• Dia. of bias drum : Max. 470 mm
• Lining cloth width : Max. 670 mm Dia. of lining cloth drum : Max. 280 mm
• Rotation rate of drum : Min. 50 RPM ~ Max. 220 RPM ( Adjusting by timer)
• Speed of under stitcher : 5 ~ 40 mm / 1 Revolution of drum (Adjusting by timer)
• Main spindle motor : 3 HP x 6 P Induction motor with 5 HP motor drive
• Under stitcher motor : 1/2 HP x 4P x 1/5 Gear reducer with 1 HP motor drive
• Bias servicer motor : 0.5 HP x 4P x 1/15 Gear reducer
• Compressed air pressure : 8 ~ 12 kgf/cm2
• Overall dimensions : L 2600 x W 2230 x H 2000 mm
• Machine net weight : Main machine 1265 kgs, Bias servicer 710 kgs
• Tire building rate : 2 Ply : 420 pcs / 8 hrs, 4 Ply : 320 pcs / 8 hrs
