Advantage :

   Qingdao chang jie machinery co., LTD., the Austrian Cincinnati technology, design and manufacture of advanced production lines,

   Pp-r, PE - RT, PB series plastic pipe production line is mainly used in the production of agricultural water supply, building water supply, centralized heating system, solar hot water system, etc. The unit by the main extruder, high pressure head body, vacuum calibrating bench, the tractor, a chipless cutting machine, double location coiling machine, etc. Single screw extruder and tractor adopt import frequency conversion,   Speed regulating device, vacuum pump and drawing motor adopts high-quality products,

Qingdao chang jie machinery co., LTD design and manufacture of similar production line to replace part of the mold can produce PP, PE, ABS, PPR, PE - RT, PB \ silicon core pipe and other pipe materials.

Application of :

1.Build hot and cold water system, including central heating system.

2.Build heating system, including floor,wall and radiant heating system.

3.Central air condition system.

4. Adopts co-extrusion die head plus assistant marking line for PB pipe.

Technical Parameters

1.0 Hopper Loader

2.0 Vacuum Sucker

3.0 SJ65 Exruder

4.0 Melt Pump

5.0 Mould

6.0 Soaking Cooling Water Tank

7.0 Soaking Cooling Water Tank

8.0 Caterpillar Haul Off

9.0 Double Coiler

Polyolefine single screw extruder is suitable for the manufacture of many polyolefine product such as: PP-R, PB, PE, PE-X pipe e

Pipe marking line is extruded by smaller single screw extruder through the composited extrusion die.

Vacuum calibration water tank: it is equipped with two-stage vacuum system(for large diameter)advanced water recycle & high pressure cooling system, vacuum degree adjustment device and accurate water level & water temperature automatical control system. The accurate stannum bronze calibratation sleeve ensures fast cooling speed and molding of pipe. Its material is stainless steel.

Spray cooling water tank: Long cooling unit ensures high efficiency cooling, Unique pipeline design shorten cooling length. Accurate water level & water temperature automatical control system realize precise temperature control. Tank upper section made from stainless steel.

Hauling unit: highly wear-resistant rubber V-shaped pads, special upper and lower lifting devicesimplize the production of different pipe diameter, strong abrasion resistance in caterpillar , stable and high speed pulling force.

Cutting unit: Unique scrapless cutting structure to ensure the perfection of pipe end, Scrapless cutting with the characteristics of low noise and energy saving, Advanced follow-up design to ensure the accuracy of pipe cutting, the cutting section is flat and smooth with high precision and low noise.

PLC computer control system with touch screen interface can realize automatic and reliable operation.

Technical Parameters:
