PE Water and Gas Pipe Supply Production Line
產品型號:GF-63 GF-110 GF-160 GF-250 GF-400 GF-630 GF-
產品特色
This line can also be equipped with length-measuring and thickness increasing instruments . This line is characterized of reliable performance and high production efficiency . anti-noise spiral pipe and foam core pipe production lines are also available according to customers requirement.
產品規格
PE pipe production line is mainly used in the production of water supply and drainage pipes , which used for agriculture and construction , cable coating and other fields , the complete line is consisted of extruder , vacuum calibrator , hauling machine ,cutter and tipping rack , hauling machine unit has come ways of hauling , such as caterpillar type, three-claw type , four-claw type , six-claw type and so on . there are also knife-lifting cutter and planetary cutter
This line can also be equipped with length-measuring and thickness increasing instruments . This line is characterized of reliable performance and high production efficiency . anti-noise spiral pipe and foam core pipe production lines are also available according to customers requirement.
| Model | GF-63 | GF-110 | GF-160 | GF-250 | GF-400 | GF-630 | GF-800 |
| Diameter range(mm) | 16-63 | 16-110 | 32-160 | 63-250 | 160-400 | 315-630 | 450-800 |
| Haul off caterpillar | 2 | 2 | 2 | 3 | 4 | 6 | 8 |
| Drawing force(kw) | 6 | 8 | 11 | 20 | 30 | 40 | 50 |
| Drawing speed(m/min) | 15 | 12 | 9 | 8 | 4 | 2 | 2 |
| Down stream power(kw) | 14 | 14 | 14 | 21.5 | 41 | 56 | 64 |
