Digital Universal Length Measuring Machine ULM-1067H



產品型號：ULM-1067H

產品分類：自動化設備/產業機械 / 檢測設備 / 檢測、量測設備及其另件



立即線上詢問





產品特色



Features:
* High-quality castings, under long-term natural aging treatment, are selected for the foundation, with fine stability
* Optimized square design is adopted for the spindle to assure the stability of its kinetic property under measurement
* Accessories with powerful and multiple functions may be selected to satisfy different requirement in measurement
* The infrared light-emitting component, with low voltage, small current, small volume and long life are adopted as the light source in the grating lighting system
* The high-precision measuring system is adopted for this instrument, which would be in conformity with the Abel Principle and with high precision in measurement
* ULM-1067H: The powerful function of the software, can not only correct the indicated errors, but also automatically correct the measured errors caused by temperature,and the software has the function of automatically discriminating the turning point
Usages:
As the length metrological instrument, The Length Measuring Machine is for direct and differential measurements, it is mainly used in metal-working industry, especially the inspection department of those industries of machine manufacturing, measuring tool and gauges together with measuring instruments. It is the high-technology product of the integration of the optics, mechanic and electricity and adopts the grating displaying technology, which has greatly improved the accuracy and efficiency. At the same time, it various accessories have improves the universal performance. Its measuring parts are as follows:
a. Smooth cylindrical workpieces such as axis, hole, gauge and ring gauge
b. The pitch diameter of internal and external thread, thread gauge and thread ring gauge
c. Workingpiece with parallel plane surface, such as measuring rod and lower grades gauge.

Main Functions:
1. Absolute measurement and comparison measurement for the external dimension
2. Internal dimension measurement
3. Measuring accuracy for the internal and external dimension
4. Measuring the internal and external threads
5. Segment compensation for the grating value, linear compensation for the grating value, temperature compensation
6. Input date and modify data by keyboard, delete coordinate point
7. Open documents and save coordinate point
8. Grating data imaging and finding reversal point
9. The measuring results import Excel and Print measuring results.
