Salt Spray Tester
產品型號：TNJ-025
產品分類：自動化設備/產業機械 / 檢測設備 / 檢測、量測設備及其另件
產品特色
Salt spray tester adapted to the surface treatment of various materials, including paint, electroplating, organic and inorganic coating, anode processing, antirust oil and so on, after these anti-corrosive treatment to test the corrosion resistance of their products.
Material:
1) Laboratory using PVC sheet, thickness 5 mm, the temperature reaches 80 degree Celsius;
2) Laboratory closure with high impact acrylic sheet, 6 mm thick;
3) Supplementary bottles of reagents attached to the water level perspective with hidden windows, clean easy, not easy to break;
4) Saturated air barrel using SUS #304 stainless steel barrel high pressure barrel insulation is best;
5) Laboratory basketball adopt flat indexing frame, adjustable angle, surrounded by mist side down exactly the same place the large number of test pieces
產品規格
Inner Box Size (L× W× H) 90× 60× 50 cm
Outside Box Size(L× W× H) 141× 88× 128 cm
Temperature Range 35 centigrade degrees to 55 centigrade degrees
Temperature Fluctuations ≤ ± 0.5 centigrade degrees
Temperature Uniformity ≤ ± 2 centigrade degrees
Temperature Precision ± 1 centigrade degrees
Test Chamber Temperature Salt Spray Method (NSS ACSS)35± 1 centigrade degrees
Corrosion-resistant Testing Method (CASS) 50± 1 centigrade degrees
Saturated air Barrel Temperature Salt Spray Method (NSS ACSS)47± 1 centigrade degrees
Corrosion-resistant Testing Method (CASS) 63± 1 centigrade degrees
Brine Temperature 35 centigrade degrees± 1 centigrade degrees
Spray Quantity 1.0~2.0 ml / 80cm2 / hr
PH Salt Spray Method (NSS ACSS6.5~7.2)
Corrosion-resistant Testing Method(CASS)3.0~3.2
Lab Volume 270L
Brine Tank Capacity 25L
Power AC220V, 10A
Multiple Safety Protection Devices Current discharge protection, over pressure protection, over temperature protection, over load fuse protection
Accessories Testing Salt/ Measuring tank/ Equipment each 1 set
Standard CNS: 3627, 3385, 4159, 7669, 8886;
JIS: D0201, H8502, H8610, K5400, Z2371;
ISO: 3768, 3769, 3770;
