產品規格

Broken tap buster description:
1.Small size, light weight, convenient to operating;
2.Electrolytic Corrosion principle, no damage to workpiece
3.Magnetic base, easily to attract on the workpiece
4.Cooling fan installed keep the machine contiinue working
5.Working head is separated, helpful for complex machining
6.Alarm automatically for preset depth.
7.Tap water as working liquid, moderate power consumption.
8.Wide processing range:broken taps and drills above φ3mm.


Broken tap buster specification
Name ----------------------- broken tap buster EDM-8C
Input Voltage (V)-------------- AC220V 50/ 60Hz
Secondary Output Voltage (V)--- 10-70
Electrode Diameter Range------- 1-10mm
Max Travel of working head (mm)- 70mm
Max Processing Speed(mm/ min)--- 1mm/min
Working Liquid ---------------- Tap water
Power Frequency--------------- 50Hz
Remove Taps Sizes(mm)----------- M2-M30
Machine Size (L*W*H mm) -------- 380*160*300mm
Package size ------------------- 498*308*392mm
Net weight(KG) ---------------- 14KG
Gross weight ----------------- 16KG
Function------------------------ Remove broken taps, dreamers and screws.
