CNC Milling Machining Centers VL1160
產品型號：VL1160
產品分類：工具機產業機械 / 綜合加工機 / 立式綜合加工機
產品特色
Quality
The outstanding machine performance relies on precision parts. To ensure each part achieves the highest accuracy and dependability, our Q.C department conducts 100% parts inspection.This combines with the use of a full series sophisticated inspection instrument to ensure only best quality parts fitted on all machines.
1-----Each spindle motor is subject to dynamic balance calibration before it been assembled to machine.With this process applied minimum spindle motor chattering maximum machining accuracy can be achieved.
2-----Renishaw Laser calibration system ensure machine accuracy.
3-----Renishaw Ball bar system,circular test ensures machine geometry
產品規格
Please visit our website for more information: www.botecnc.com
|
|
VL1160---Linear guideways in 3 axes |
|
|
Travel |
X axis |
1100mm |
|
Y axis |
600mm |
|
|
Z axis |
750mm |
|
|
Spindle nose to table |
150-900mm |
|
|
Spindle nose to column |
659mm |
|
|
Feed |
max X rapid feed |
48 m/min |
|
max Y rapid feed |
48 m/min |
|
|
max Z rapid feed |
48 m/min |
|
|
Cutting feed |
1-10m/min |
|
|
Torque |
X:20N.m Y:20 N.m Z:20N.m |
|
|
Table |
Table size |
1200*600mm |
|
Max load |
700Kg |
|
|
Table surface to floor |
950 mm |
|
|
T slot |
5*18*100mm |
|
|
Spindle |
Type |
Belt |
|
Speed |
8000 rpm |
|
|
Spindle taper |
BT40 |
|
|
Main motor |
11KW |
|
|
Accuracy |
Accuracy (JIS) |
0.005/300mm |
|
Repeatability (JIS) |
0.003mm |
|
|
Other |
Weight |
7000 Kgs |
|
Size |
3200*2500*2900 |
|
