CO2 LASER ACRYLIC/LEATHER/PAPER/EPOXY RESIN ENGRAVING CUTTING MACHINE
產品型號:DM-3050
產品分類:自動化設備/產業機械 / 自動化設備 / 雷射切雕刻機
產品特色
This machine adopts imported high-speed Mute linear Guide.liner rail are zero wear,slider of bearing wear can adjustable compensation.Rail,Belt and Aluminium profile are integrated design,be more save place.And to better ensure the blance of linear guides,very beautiful outward appearance,more easy maintenance.Machine uses USB port to transmit data,equipped withlarge-capacity internal memory, improving working speed and efficiency greatly.Complete function , safe and stable , exclusive complete water protection system , to protect the working life of the laser tube effectively .The power control system has exclusive automatic protection equipment to ensure the stability and safety of the machine to the best .Electronic controllift platform , easy to feed front and back , easy and flexible to operate ,can engrave materials with different heights .adjustable height: 200mm Our laser machine also with AutoFocus function.Red light positioning system realizes the high positioning without laser .Adopting the honeycomb platform, easy for small materials engraving and cutting.Also have strip shape platform for optional ,which can bear heavier materials such as organic glass, wood and so on.(Optional) Doublehead adoption enhances processing speed twice.
Our laser power testing can make sure the two laser tubes inside have same power so that the materials. both sides have the same effect.DM3050 is most suitable and the preferred choice of equipments in industries such as advertisement, gifts, shoes, toys, and etc.
For detailed information ,pls emai for us or check our website. www.china-bestlaser.com
[email protected]
[email protected]
產品規格
Model DM.3050
LASER TUBE Water cooling Co2 sealed glass
Control system 32 Bit DSP
LASER HEAD CO2 laser head
Drive typeMicrostepping stepper motor system
Auto focusOptional
Laser Power 50W (60W FOR OPTIONAL)
Work Area (Mm) 300x 500
Max speed 1000 mm/s
Image form Plt, Dxf, Bmp, Ai, Dst
Resolution2500 DPI
Double HeadOptional
PC Interface USB2.0 and USB Disk
Red Dot Pointer Optional
Accessories Air assistant, Exhaust system, Water
Power110V or 220-240V/ 50~60Hz
Warranty 24 Months
Machine Size WxDxH (MM) 1150*670*890
G. W. (Kg) 125
