Touch Type - Automatic Vacuum Siphon device TWS-V2
產品型號:TWS-V
產品特色
It is a device to extract vacuum when working on waterproofing of porous products, removing air bubbles between powders and particles, removing air bubbles between viscous liquid molecules, turning over molds, and making epoxy, silicone, and wax models.
The machine is researched and designed according to the standards of ASTM B311, B328, MPIF42, MPIF 57, JIS Z2501, Z2505, Z2506, GB/T 5163, 5164, 5165.
產品規格
Principle:
The machine is researched and designed according to the standards of ASTM B311, B328, MPIF42, MPIF 57, JIS Z2501, Z2505, Z2506, GB/T 5163, 5164, 5165.
Suitable for: | Features: | |
1. Waterproofing before testing the green density, sintered density, and oil content of powder metallurgy. 2. Waterproof treatment before testing the green density and sintering density of magnetic materials, precision ceramics, silicon carbide, and refractory materials. 3. Saturated water treatment during the basic density test of wood. 4. Saturated water treatment operations during the bulk density test of the absorbent sponge. 5. Equipment for drawing vacuum when turning molds, making epoxy, silicone, and wax models. 6. Saturated water treatment during the bulk density test of EVA/PE foam. 7. The equipment to extract vacuum when researching and experimenting on porous water-absorbent materials. |
1. This machine has two vacuum extraction time settings Timer 1 and Timer2. It can be timed from 0 to 99 minutes. 2. This machine has the function of injecting liquid into the vacuum desiccator. 3. Liquid injection hole: 4. Pressure regulator: |
Model: | TWS-V2 |
Main Body Dimension: | 42cm (L) * 30cm (W) * 45cm (H) |
Vacuum Desicator Dimension: | 15cm (Diam) * 9cm (h) |
motor Power: | 120 W |
Motor Voltage: | 110 V / 60 Hz |
Motor Pascal: | 10 Pa |
Motor Pumping speed: | 1 L / S |
Motor Rotation Speed: | 1400 r / min |
