產品規格



Max.planing width 300mm
Max.planing capacity 3mm
Max.rabbet cutting depth 10mm
Max.sawing thickness 85mm
Press planing thickness 6-120mm
Min.press planing length 150mm
Max.tenon & drilling dia. 13mm
Cutter spindle speed 3500r/min
Press planing feeding speed 6.5m/min
Sawing arbor speed 3500r/min
Max.cross-cutting width 300mm
Index ruler adjustmert +/-45degree
Motor power 1.5kw/2.2kw
N.W./G.W. 275/300kg
Packing size 1360x810x570mm
