產品規格

Product Keyword

Application: Cutting, Grinding, Welding, Blending etc,

Filtering effiecny:99%

Power supply:380V/220V 3P 50Hz

Filtration Principle: Cartridge Filtering

Filter Material : ePTFE

Noise:75dBA

Filter life: 12 months

Cleaning: Pulse-jet cleaning

Inlet:  Top

Outlet: Lateral

Housing life:20 years

Installation : Mobile

Working Principle:

At first, the dust air is inhaled into the first filter airflow balance version by the universal suction arm, to avoid the dust air focus on the same direction, meanwhile, intercepting the spark, that forms the first filtration. Next, the dust air will impact with the primary filter. It will filter down some dust air. Then through the primary filter to enter the core cartridge filter and captured. At last, the tiny dust through the outlet filter before the air outlet, the dust was cleaned completely.
