UHF 433 MHz RS-232 adapter
產品型號：UHF-232
產品分類：自動化設備/產業機械 / 自動化設備 / 工業用機器人及週邊設備
產品特色
Features:
UHF 433 MHz
Configure RS-232 parameters via COM port
1 to 1 connection will Ack the data
1 to N broadcast will not Ack the data
Cable replacement, >200 meters
Applications:
PDA, POS, Smartphone
Receipt printer
Bar code reader
RFID reader
IC card reader
MSR card reader
PLC, CNC machine
Robot, UAV
SCADA, data collector
產品規格
Specifications:
Support TXD/RXD/CTS/RTS
Frequency bands: 433 MHz@FSK modulation
TX power: up to 17 dBm @ 433.92MHz, Distance: 200-300m
Low consumption: TX: 30mA, RX: 14mA @10dBm
RF Data Rate : 100 Kbps
Receiver Sensitivity: -103 dBm @250K bps
Support software and API setting for Baud rate option
Baud rate: 1,200/2,400/4,800/9,600(Default )/19,200/38,400
57,600/115.200 bps
Hopping Frequency: 433.3MHz, 433.6MHz, 434MHz, 3 Chanel
