產品規格

Specifications:

■ MCU: ARM 32-bit CortexTM-M3
■ Network standard: 802.11b, 802.11g, 802.11n(single stream)
■ Frequency band: 2.4GHz
■ Transmit power:
● +17dBm @802.11b
● +13dBm @802.11g
● +11dBm @802.11n
■ Minimum receiver sensitivity: -80dBm
■ Hardware encryption: WEP, WPA/WPA2
■ Antenna: SMA type 2 dBi dipole (Default)
■ 1 TCP Server to 5 TCP Clients Broadcast; Each client will unicast to the
server
■ Operational temperature: -40ºC to 85ºC
■ COM Port: 8 Data Bit, 1 Stop bit
● Baud rate: 9,600~921,600 bps, Raw value (self defined)
● Parity: None, Even, Odd
■ TCP Server/Client, Http Client
■ NTP time mark added with UART data for Internet of Things (IOT) applications
■ WiFi: AP, Station, Dual (AP + Station)
