Silicone Coated Fiberglass Fabric
產品型號:Silicone Fabric
產品分類:包裝印刷暨食品及製藥機械 / 包裝機械 / 塑膠袋熱封口機
產品特色
Silicone Coated Fiberglass are made from woven fiberglass substrates that have been coated on one or both sides with silicone rubber. It has characteristics quite similar to those of PTFE-coated fabrics: Good temperature resistance, good chemical and electric resistance. But they are more flexible and very non-stick. On the other hand, silicone has a non-slip surface, unlike PTFE. These fabrics are widely used for manufacturing of removable, reusable insulation pads, jackets, Matresses for Valves, Turbines, Equipment requiring frequent
Inspection and maintenance in high temperature and HVAC Chilled waterapplication.
Properties:
- Hi - temperature resistant (up to 230 ° C)
- Excellent release properties
- Superior abrasion resistance
- Good chemical resistance
- Superior dielectric properties
Applications:
- shrink tunnels
- foam manufacturing
- electrical insulation tapes
- conveyor belts for industrial processes
- safety curtains
- release and separator sheets
- gasketing, and for packaging, food, printing, chemical and rubber industries
Main Specification:
產品規格
Silicone Rubber Coated Glass Fabrics | |||||
Model | Thickness mm |
Breaking Strength (n/50mm) |
Bursting Strength (Mpa) |
Combustible | Width |
5015 | 0.15 | 1500/1200 | 2.0 | ≤25% | 0_1500mm |
5025 | 0.25 | 1800/1500 | 2.1 | ≤25% | 0_1500mm |
5040 | 0.40 | 2000/1600 | 2.2 | ≤25% | 0_1500mm |
5050 | 0.50 | 2200/1800 | 2.3 | ≤25% | 0_3000mm |
5060 | 0.60 | 2400/2200 | 2.4 | ≤25% | 0_3000mm |
5070 | 0.70 | 2500/2300 | 2.4 | ≤25% | 0_3000mm |
5080 | 0.80 | 2600/2400 | 2.5 | ≤25% | 0_3000mm |
5090 | 0.90 | 2800/2600 | 2.5 | ≤25% | 0_3000mm |
5100 | 1.00 | 3000/2800 | 2.6 | ≤25% | 0_3000mm |
5120 | 1.20 | 3400/3000 | 2.5 | ≤25% | 0_3000mm |
5150 | 1.50 | 3700/3300 | 2.8 | ≤25% | 0_3000mm |
5200 | 2.00 | 4200/3800 | 3.5 | ≤25% | 0_3000mm |
5300 | 3.00 | 6500/6200 | 5.0 | ≤25% | 0_1000mm |
