APPLICATION

Used for desizing,bleaching ,scouring of cotton,hemp,polyester fabrics and their blends.

The whiteness effect is enhanced, thus the quality of the fabric can meet the requirement of the post-process

 TECHNICAL FEATURES:

(1)Building block type structure, to combine different process lines in need of different products.

(2)Steamer structure: single layer, single layer complex or double layer complex type.

(3)Preheating section: big rollers, multi-point, common source frequency conversion transmission, less crumples, suitable for high density elastic fabrics.

(4)High add-on unit can increase liquid quantity to ensure fabric suck chemicals fully.

PROCESS FLOW:

 Unrolling, open width→Spray Washer→Two bowl padder→Washer→Two bowl padder→Washer→Two bowl padder→Trough (Automatic dosing system) →Two bowl padder→Steamer→Washer→Two bowl padder→Washer→Two bowl padder→Washer→Two bowl padder→Washer (PH control system) Two bowl padder→Cylinder dryer (2 stacks, 24 cylinders)→Plaiting in batching

(or according to clent's requirement)

MAIN SPEC

(1)Machine width  :1800-3600mm          (2)Machine speed     :10-80/100 m/min

(3)Steamer capacity:3000-8000m          (4)Preheating section capacity: 16-80m

(5)Guide roller diameter : 180-200mm   (6)Touch screen  :Weinview brand

(7)Inverter   :Schneider brand               (8)PLC :Mitsubishi brand

OEM: our factory can custom according to your requirement

with our excellent engineers who have more than 10 years experience.
