產品規格

Controlled Axes                                                                n° 1

STROKES

Max working length ( stand. )                                            mm    1200

Max working length ( opt. )                                               mm    2200

Min working length                                                           mm    150

Max tenon width                                                               mm    100 + 2R

Max tenon depth                                                              mm    40

Min tenon depth                                                               mm    10

Max. tenon thickness                                                         mm    25

Inclination of the heads                                                     +45° - 22°

MOTORS POWER

Motor for cutter rotation                                                   HP      4 x 2

Motor for cutter revolution (with inverter)                           HP      1 x 2

Motor for movement of the R.H. unit                                  Hp      1

SPEED

Cutter holder shaft speed  ( stand. )                                   RPM   9000

Cutter holder shaft speed  ( opt. )                                      RPM  12000

TOOLS

Cutters supplied with the machine                                      n° 2

DIMENSIONS

Overall dimensions with stroke X =1200                             3200x1650x1800mm
