Woodworking Hydraulic Cold Press
產品型號：MH3248X50
產品特色
Wood Cold Press Machine
1.with quality electric part
2.max pressure:50t
3.plywood making machine
4.long service time
產品規格
USE OF THE MACHINE
The machine is applied for modern fashion board,plyboard,flak-board,laminating board.woodbased panel board,furniure manufacture,solid board furniture,speaker box,plastic and wooden mould etc.Easy to operate,working exact and fasthigh efficiency,it is the necessary pressed workpiece equipment in artifical panel,the composite furniture and solid board furniture manufacture material.
MAIN SPECIFICATION AND TECHNOLOGY PARAMETER
|
Worktable size(L×W)
|
1250×2500mm
|
|
Max pressure of worktable
|
50t
|
|
Pressing-plate max open distance
|
1000mm
|
|
Oil cylinder
|
Φ125mm×2pcs
|
|
Hydraulic pump power
|
5.5kw(7.4HP) 380V 50Hz
|
|
Weight of machine
|
2780kg
|
|
Overall dimension(L×W×H)
|
2930×1250×3130mm
|
Advantage:
1.adopting auto-manual functions, may choose auto and manual control function separately.
2.Auto-pressure regulating oil circuit (line) function
3.Auto-adding and auto-holding pressure function
4.With Safety device(safety catch)
5.Emergency safety brake function
6.With excellent electrical parts
7.Stable and easy to operate
8.the worktable is milled by special machine, flatness error conform to national standards
