Spline milling machine
產品型號：ZFWVG 250/3W*800
產品特色
Spline milling machine ZFWVG 250/3W*800
Some information:
Spline milling machine ZFWVG 250/3W*800
1991 year of manufacturing
Heckert, Germany
產品規格
Specification:
workpiece dia. over bed 500 mm
hobbing length 800 mm
max. module 7 / 8
number of teeth 2 - 50
workpiece dia. over saddle 250 mm
center height over bed 260 mm
workpiece spindle bore 102 mm
total power requirement 9,5 kW
weight of the machine ca. 3,4 t
dimensions of the machine ca. 2,8 x 2,5 x 1,6 m
Condition:machine is like new one, there is full box of new accessories
