bevel gearbox
產品型號：RNV-065~RNV-260
產品分類：自動化設備/產業機械 / 自動化設備 / 自動矯正機
產品特色
Bevel gearbox RNV-Series, cubic shape of gearbox.
Model: RNV-065, RNV-090, RNV-120, RNV-160, RNV-200, RNV-260
Function: Right angles change transmission directions
Configurations: Spiral bevel gears, bearings, gearbox, input and output shafts
Materials:
1. Spiral bevel gears: Alloy steel, case hardened, be of high rigidity and wear risistance
2. Bearings: Taper roller bearings, bear larger torque
3. Gearbox: Cast iron, six faces of gearbox are machined by milling machine, gloss surfaces
4. Input&Output shaft: S45C, heat treated
Speed Ratio: 1: 1, 2: 1. Special ratio, following clients' orders
Transmission Efficiency: 95%
Gear Oil: HD320~680
Max Revolutions: 1450 rpm
Ambient Temperature: -20 degree C~+80 degree C, special temperature, consult our engineers
Noise Level: Less than 80 dB
Temperature Level: Less than 50 degree C
Test Equipments: Noise meter and infrared thermometer
Application Industries:
Diesel engine drive water pump, textile, food processing machine, medicine, rotary axis drives, conveyors, packaging equipment, material handling, automation and packaging etc.
產品規格
RNV-065, RNV-090, RNV-120, RNV-160, RNV-200, RNV-260
