Rebonded foam machine
產品型號：ERS-R01/R02/R03 Rebonded foam machine
產品分類：紡織染整成衣暨縫製機械 / 製鞋產業 / 紡織•布類
產品特色
The machine is mainly used to crushing foam has been mixed with glue, then through the mould, pressed by the hydraulic system, the corresponding density of the regeneration of sponges required. The machine has a stirring, mixing, compression molding a set of assembly line and production efficiency. Chooses to use the automatic steam moulding, the production efficiency 6-8 times .
Technical specification
Model ERS-R01 ERS-R02 ERS-R03
mixing box cubage 10m³ 10m³ 12m³
mixing speed 40r/min 40r/min 40r/min
total power 15kw 18kw 22kw
moulding size L2050*W1550*H1000mm（2pcs）manual L2050*W1550*H1850mm（1pc）automatic L2050*W1550*H1850mm（1pc）automatic
machine external size L6000*W3600*H5300mm L6000*W3600*H5500mm L6000*W3600*H5800mm
產品規格
Model ERS-R01 ERS-R02 ERS-R03
mixing box cubage 10m³ 10m³ 12m³
mixing speed 40r/min 40r/min 40r/min
total power 15kw 18kw 22kw
moulding size L2050*W1550*H1000mm（2pcs）manual L2050*W1550*H1850mm（1pc）automatic L2050*W1550*H1850mm（1pc）automatic
machine external size L6000*W3600*H5300mm L6000*W3600*H5500mm L6000*W3600*H5800mm
