Automatic Vacuum Forming Machine
產品型號：JG-ZXC
產品特色
The machine adopts the international newest plastic sheet forming technology with computer digital forming system and PLC electromechanical integration full-automatic control.The touch screen can control all action system. It has the following advantages: convenient operation,saving material,improving production efficiency, reliable stability,large forming area, easy operation, quick forming speed, high automation and so on. The machine is plastic sheet forming equipment in one step with following process: transporting sheet, heating, forming, punching, stacking and winding waste edge
產品規格
Max.forming depth: 120 mm Heating power: 53 KW Production efficiency: 4-10 Mold/min Air source: 0.8-1 Mpa Install area of punching mould:640×1080 mm2 Effective punching area: 620×900 mm2 Max.punching depth: 150 mm Punching force: 15 T Insatlled capacity(approx): 90 KW Dimensions(approx): 14×2.2×2.1 m Total weight(approx): 8 T
