產品規格

Specifications

Product name: Metal Screen

Main types: Perforated screen panel, laser cut screen panel, framed fence screen, partition screen

Material: Q235 carbon steel, galvanized steel, aluminum sheet, stainless steel 304 or 316

Panel thickness: Commonly 1.0 mm to 3.0 mm for perforated panels. Thicker plates can be made for heavy duty guards.

Frame material: Square tube or rectangular tube, commonly 30 x 30 mm, 40 x 40 mm, 50 x 50 mm, or made by drawing

Post type: Square post with base plate, embedded post, or custom fixing bracket

Panel size: Common fence panel sizes include 1000 x 2000 mm, 1200 x 2000 mm, 1500 x 2000 mm, and 1800 x 2000 mm. Custom height and width are available.

Hole pattern: Round hole, square hole, slot hole, diamond hole, geometric cutout, decorative laser cut pattern

Surface finish: Powder coated, galvanized, hot dip galvanized, or stainless steel natural finish

Color options: Yellow, blue, red, green, black, white, silver, and other RAL colors

Installation: Base plate fixing, bolt connection, welded frame, or post mounted system

Application

Fence and boundary panels: Used for factory areas, public facilities, machinery zones, and commercial boundaries.

Indoor and workshop partitions: Suitable for separating work zones while keeping light and airflow.

Equipment and safety guards: Used around machines, production lines, and service areas where visibility is needed.

Decorative screening: Applied to building facades, garden dividers, balcony panels, and architectural partitions.

Products and Specifications

Powder coated perforated screen partition, 2000 x 1200 mm

Powder coated perforated panels for indoor partition fencing and workshop separation. The white and yellow panels give clear area division without closing the space fully.

Specifications: Material: Q235 steel sheet. Panel size: 2000 x 1200 mm. Sheet thickness: 1.5 mm to 2.0 mm. Hole type: round or square perforation. Frame: 40 x 40 mm steel tube. Finish: powder coated.

Use: Factory partition, walkway separation, warehouse safety line, indoor fence screen.

Black laser cut decorative screen panel, 1500 x 1000 mm

Laser cut screen panel with a leaf style pattern and black coating. This model is more suitable for decorative fencing and privacy screen projects than heavy impact protection.

Specifications: Material: carbon steel or aluminum sheet. Panel size: 1500 x 1000 mm. Plate thickness: 2.0 mm to 3.0 mm. Pattern: laser cut decorative design. Frame: welded side frame. Finish: black powder coating.

Use: Garden screen, balcony privacy panel, commercial partition, architectural metal screen.

Green geometric screen panel, 2000 x 1000 mm

Geometric metal screen panels shown during coating and workshop handling. The open pattern allows air movement and gives a lighter visual effect than solid plate fencing.

Specifications: Material: Q235 steel plate. Panel size: 2000 x 1000 mm. Plate thickness: 2.0 mm to 3.0 mm. Pattern: geometric laser cut. Frame: welded steel frame. Finish: green powder coating.

Use: Fence infill, garden divider, facade screen, outdoor partition.

Silver perforated panel with yellow posts, 1600 x 1200 mm

Framed perforated panel with yellow side posts and a silver screen surface. It can be used as a modular barrier where a lighter color panel is needed.

Specifications: Material: galvanized steel or powder coated steel. Panel size: 1600 x 1200 mm. Sheet thickness: 1.2 mm to 1.5 mm. Post: square tube with base plate. Hole type: small square perforation.

Use: Workshop partition, indoor safety screen, equipment area guard, display area barrier.

Blue perforated screen with white posts, 1800 x 1500 mm
