Characteristics

1. The packing machine is developed to meet the automatic operating for packing the fabrics in large lot. Compared with the tranditional packing, it can saving the manpower, improving efficieny and making the apperance of packing more beautiful.

2. It use screen control system for easy operation and can reduce the maintenance, automatically detect faults.

3. The packing sealing knit , after special treatment, is durable and have a service life of more then 3 years. It can be used for various PE films, with a sealing success rate of 100%.

4. The side sealing suction device is equipped with a sound attenuation system to reduce noise.

5. For products that do not need heat shrink packing, energy consumtion can be saved.

6. The machine can automatically packing fabrics in different diameters, size and lenghts

Packing Size

1. Suitable for high density and low density PE

film

2. Packing diameter is 100-550MM, the max. width of PE film is 2750mm, and max. fabric width is 2400mm to packed

Specifications

1. Sealing mode: centering and fixing mode for left and right sealing knit suction

2. Main sealing movement part: pneumatic control, electric heating power 3.2KW

3. Sealing knif material: alloy copper

4. Knit sealing protection: electric eye detects fabric clamping alarm

5. PE film thickness: 0.04-0.1 mm

6. PE film length: 2000-2750mm

7. Air cylinder: magnetic induction

8. Packing speed: 4-6 rolls/min

9. Packing machine dimension: W3900 X L2765mm X H1920mm
