1

Machining Hole Diameter

Ø12-Ø200mm

2

Allowable load of table

200kg

3

Maximum stroke Depth

600mm

4

Spindle motor power

1.5KW

5

Spindle reducer ratio

3：1

6

Spindle Speed range

100-1000rpm(CVT)

7

Return Oil Pump flow

100L/min

8

Stroke Motor

2.2KW

9

Stroke Control Type

“Servo Motor+Ball Screw”

10

Stroke Speed

0-40m/min(CVT)

11

Honing tool Qty

1 Axis

12

Single Working Station

1（Single Honing tool）

13

Feeding Torque

≥20NM

14

Honing Accuracy

≤0.1mm

15

Feeding Type

Constant feed

16

Machine Weight

About 2.5 Tons

17

Machine Size L×W×H

1500×1500×2700mm

18

Noise standard

Less 80 dB Normally
