產品規格

1. The operation is simple, no need to paint and design personnel, only need to operate the wall painting machine proficiently to paint a beautiful world.
2. It avoids the slow speed and high price of manual painting in traditional wall painting; the single color of mold sticker painting, low precision and easy disconnection from the home decoration style, and the inconsistency with the home decoration; and the disadvantages of poor selectivity in soft mold painting.
3. The pattern pictures painted by the wall painting machine are fine and vivid, with high color reproduction and strong three-dimensional effect, which makes people have an immersive beauty.
4. The wall printing machine works**, which can paint 3-6 square meters of walls per hour on average, with low ink usage and low cost.

Product parameter

Print head Epson DX7
Inkjet Technology Smart Micro Piezo Inkjet Technology
Ink uv ink
Ink supply system 88ml positive pressure continuous ink supply system
Applicable wall surface Rigid flat wall such as putty wall, latex paint wall, white wall, imitation porcelain wall, concrete wall, etc.
Printing accuracy 720*1440dpi, 720*720dpi, 720*360dpi.
Voltage 220V±15%
Frequency 50Hz
Generator Servo/Stepper
Printing direction Vertical
Print size 1.9m*4.5m
Application environment Wind power below level 5 5/5-35℃/no rain or snow
Storage environment dry -20℃-60℃
Noise standby＜20db, printing＜55db
Speed 2 channels 8 m2/h, 4 channels 5 m2/h, 8 channels 2.5 m2/h
Main chip US altera 4
Storage chip Samsung s3.16G internal memory
Interface USB
Signal transmission optical fiber
Language Chinese/English
Color black, red, yellow, blue four colors
Printing thickness 10-15g ink or 15-20ml ink/m2
Control distance Self-control the distance between the wall and the nozzle (single sensor)
External dimensions length 5m*width 0.75m*height 2.56m
Weight 55Kg
