Aluminum Die Cast Mold Accessories

Die cast mold ejector pin. Material DIN 1.2344, AISI H13, JIS SKD61, ASSAB8407

Ejector pin with a cylindrical head

Shouldered ejector pin

Flat ejector pin

Forming ejector pin
SKD61 and AISI H13 is popularly in aluminum die casting molds manufactory
SKD61 inner hardness: HRC48-52, surface hardness: HV900-1100, heat treatment:
Vacuumed + nitride
H13 inner hardness: HRC 48-52, surface hardness: HV900-1100, heat

Guide pillar and guide bush

Square Guide Pillar

Ejector Guide Pillar

Headed Guide Pillar

Shouldered Guide Pillar

Ejector Guide Bush

Straight Guide Bush

Headed Guide Bush

Guide Plate

HASCO DME FUTABA standard

Roughness Ra0.6-0.8, tolerances below 0.001mm, roundness:0.002mm, concentricity: within0.002mm

Mold base company like LKM, D-M-E, FUTABA hade branch company in Ningbo. S50C is important material for aluminum die casting mold base, QT550 and QT600 was popularly material for die casting mold base in twenty years before. Since customer increasing high quality aluminum die casting mold require, the material of S50C, DIN 1.1213, AISI 5AE 1050, NF C50 is welcomed in Ningbo die casting market

Clamping plate of the fixed half

Clamping plate of the moving half

Bolster of the fixed half

Bolster of the moving half

Support pillar, space block, support plat

Aluminum Die Casting Molds Manufactory can produce die cast mold accessories and various guide pillars and guide bushes to meet customer requirements for high-quality aluminum die-casting molds.

Goalsure is one of the aluminium die casting manufacturers, with complete aluminum alloy casting equipment, and we could do aluminum casting mold making according to drawing，

If you want to customize die cast mold, please click here to leave a message.
