DN80-200mm 3"-8" M200 Portable Gate Valve Grinding Machine
產品型號:DN80-200mm
產品分類:自動化設備/產業機械 / 其他產業機械 / 磨碎機械
產品特色
DN80-200mm 3"-8" M200 Portable Gate Valve Grinding Machine
產品規格
DN80-200mm 3"-8" M200 Portable Gate Valve Grinding Machine portable valve grinding machinery portable valve grinding tools for Sale
Applicstion:Gate Valve Seat,Gate Valve Core.
Grinding scope: DN80~200(3"-8")
Motor power: 1100W
Rated Voltages: 220V
Min distance of valve seal face: B>45mm
Allowed adjustable length: L≤600mm
Operating weight: 20kg
1.M200 Portable Valve Grinding Machine Diagram
1. Main body 2.electric motor 3.power box 4.adjusting bracket 5.screw bolt 6.base 7.telescopic boom
8.arm 9grinding disc 10screw bolt 11screw bolt 12 clamping rod 13Fastening handle 14.telescopic boom lock arm 15.left or right adjusting handwheel 16.handwheel 17.sliding crame 18.screw bolt
2.OVERVIEW
Model M-200 portable valve grinder is widely used in the industries such power generation, petroleum, chemical, metallurgy and paper making as a high-tech product with national patent. It has the following characteristics:
Light, compact, and easy to carry
Split-type assembly makes installation easy and fast
Available in various field work
Applicable in grinding gate, check valves and flanges made of various materials
Grinding automatically after the installation is adjusted well
Reasonable structure design, perfect Metabo motor and high-quality imported grinding materials contribute to the grinding 3-10 times as fast as the manual one
Stepless and adjustable speed, stable power transmission and accurate lapping make the sealing face in complete contact.
3.portable valve grinding equipment Technical Parameter
Applicstion:Gate Valve Seat,Gate Valve Core.
Grinding scope: DN80~200
Motor power: 1100W
Rated Voltages: 220V
Min distance of valve seal face: B>45mm
Allowed adjustable length: L≤600mm
Operating weight: 20kg
Metals Kingdom is a China supplier of Valve Test Machine, valve tester & Grinder, Valve Pressure Test Bed, Pipe Cutting Machinery. We have a high-tech work shop. We have a complete quality management system. Choose us, you can be get most careful and thoughtful service!
If you are interested in our gate valve tester, you can click here to visit our website.
