Hot sale cheap male female straight shielded auto molded connector

• M12 Circular connector according to IEC 61076-2-104

• M12 circular connector with M12*1.0 screw locking
• Equivalent to Binder, Phoenix, Lumburger automation...
• Waterproof rating is IP67/IP68, protected from dust and water during immersion, resistant to many oils and chemical

Generally Description:

Connector Series: M12
Standard: IEC 61076-2-104
Coding: A
Gender: Female
Connector Design: Cable plug
Connector Locking System: Fix screw
Waterproof Rating: IP67/IP68

Normal Temperature: -10℃~+80℃

Material:

Connector Body: TPU
Female Contacts: Phosphorus copper with gold plated
Screw/Nut: Brass with nickel plated
Waterproof 0-ring: FKM

Electrical data:

Contact Resistance: ≤5mΩ
Insulation Resistance: ≥100MΩ
Rated Current: 3A~1A
Rated Voltage: 60V~30V
