Automatic Inner and Outer Tea Bag Packing Machine
產品型號:C18
產品分類:包裝印刷暨食品及製藥機械 / 包裝機械 / 成型包裝機
產品特色
1) Automatic multi function packaging forming machine;
2) Multi-function: with outer envelope, optional with thread and tag;
3) Suitable for all kinds of tea leaves and other ground drinking spices;
4) Featured and with brand-name parts;
5) All-round process: filing, weighing, bag forming, sealing, cutting and counting etc.
6) Manufacturing experience: twelve years;
7) Quality guaranteed: CE, ISO9001:2008.
產品規格
//Application: //
It is suitable for multi-function packing kinds of drinks granules in tea bag with thread and tag, with outer envelope, such as black tea, oolong tea, Pu'er tea, organic herbal tea, scented tea, fruit tea, flower tea and other drinks granules like coffee etc.
//Features: //
1. This machine is an automatic multi-functional tea packaging equipment with a new heat sealing type. The inner and outer bag is formed at the same time, avoiding your direct contact with the packing materials and improving work efficiency.
2. Inner bag is made of filter paper with thread and tag attached, and outer bag is made of composite materials.
3. The biggest advantage is: tag attaching and outer bag making can adopt photoelectric positioning.
4. Packing capacity, inner bag and outer bag size can be easily adjusted according to different requirements in order to achieve the best packaging results, improve product appearance and enhance the value of the product.
5. The machine adopts measuring cup filling system, and can be customized with respectively independent electric scale filling system.
//Technical data: //
Machine type: |
|
Machine model: |
C18 |
Machine name: |
Automatic Multi-function Tea Bag Packing Machine (with Outer Envelope, Thread and Tag) |
Packing material: |
Paper/Plastic,Plastic/Plastic,Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Tea filter paper, Thread, Tag paper. |
Measuring: |
Measuring cup filler |
Filling range: |
3~15ml |
Packing speed: |
40~60 bags/min |
Tag size: |
L:20~24mm , W:40~55mm |
Thread length: |
155mm |
Inner bag size : |
L:50~70mm , W:40~80mm |
Outer bag size : |
L:70~120mm , W:60~90mm |
Power supply: |
220V, 50HZ, 3.7KW |
Machine dimension : |
1250*700*1800mm(L*W*H) |
Machine weight: |
500KGS |
