產品規格

Machine comes with:

Includes machine 1set,1 steel plate,1 clamp and 1 set silicon pads for one shape/size keyboard,1 pcs metal based for installing silicon pads

Technical parameter:

Max.printing area: 150*450MM
locating precision <0.05MM
fixuping clamp method: by srew
fixuping printing pad method: by hexagonal screw
Printing speed:800PCS/Hr
Power:220V 50-60MHZ 30W  Air pressure:5-7Bar
Start-up method:panel
Scraper working style: by electronic switch
scraper pressure controller: pressure regulating valve
transversa distance:200MM
vertical distance:75MM
transeversa stroke of keyboard: 20MM
second locating stroke: 40MM

Weight: 330KG

Out dimension: 1000*500*1500mm
