2167DCL w/ Fanuc數位切削CNC車床
產品型號：2167DCL
產品特色
A powerful multi-function full CNC flatbed lathe, yet easy to use Teach-in / Playback feature allows duplicating extra identical parts in no time after initial part is machined. A user-friendly and versatile Graphic Conversational Machining Guidance provides flexibility to create programs without knowledge of G-code programming. DCL is as simple to operate as a manual lathe via convenience of electronic handwheels.
產品規格
Swing over bed: 21"
Between centers: 67"
Spindle bore: 2-1/4"
Spindle speeds: 25 ~ 2,500 rpm (3 ranges)
Spindle motor: 10 HP
FEATURES:
Fanuc 20-TA CNC control system
Fanuc industry standard G-codes
CNC assisted manual machining
Teach-in / playback operation
Graphics conversational programming
Full CNC automatic operation
Tool radius and geometry operation
CNC controlled spindle
Constant surface speed (vector control)
Three (3) electronic handwheels
High precision ballscrew to ensure backlash-free transmission
Hardened and precision ground bedways
Auto lubrication system
Built-in coolant system
Hardware overtravel limit switch for all travel directions and tailstock to prevent accidental crash
