中速灌装机(双)
產品型號:中速灌装机(双)
產品分類:自動化設備/產業機械 / 自動化設備 / 自動化控制系統
產品特色
双重填料,可以横向传输,伺服和气动系统,更准确,更高速。
伺服电机和伺服驱动器控制螺,拥有稳定和准确的不锈钢结构,将料斗与抛光内出来,让它更容易清洗。PLC与触摸屏使它容易操作,拥有快速反应,使称重系统的优点得到更真实。
產品規格
Medium-speed filling machine (duplex)
Descriptive abstract:
Medium-speed filling machine (duplex)
This series of machine is a kind of new-designed that we make it on placing the old Turnplate Feeding on one side. Dual auger filling within one line main-assist fillers and the originated Feeding system can keep the high-precision and take off the tiring cleaning of the turntable. It can do the accurate weighing & filling work, and also could be combined with other machines to buildup a whole can-packing production line. This machine could be used in filling milk powder, albumen powder, condiment, dextrose, rice flour, cocoa powder, solid drink, and so on.
Main features
The machine is dual fillers on one line. Main & Assist filling keep work in high-precision. Can-up and horizontal transmitting is controlled by servo and pneumatic system, be more accurate, more speed.
Servo motor and servo driver control the screw. Owning the stable and accurate Stainless steel structure, splitting hopper with polishing inner-out make it cleaned easily.
PLC & touch screen make it be easy of operation.
Owning the Fast-respond weighing system and it make the strongpoint to get more real.
The handwheel make the exchange of different filings to be easily.
Dust-collecting cover met the pipeline and protect environment to pollution.
The design of Horizontal straight makes the machine in little area
Settled screw setup and make no metal pollution I n producing
Process: can-into → can-up → vibration → filling → vibration → vibration → weighing &tracing → reinforce → weight checking → Can-out
Model:DCS-2B-320
Dosing mode: Dual filler filling with online weighing
Filling Weight: 100 – 2000g
Container Size: Φ60-135mm; H 60-260mm
Filling Accuracy: 100-500g, ≤±1g; ≥500g,≤±2g
Filling Speed: Above 50 cans/min(#502),Above 60 cans/min(#300 ~ #401)
Power Supply: 3P AC208-415V 50/60Hz
Total Power: 3.3 k w
Total Weight: 450kg
Air Supply: 6kg/cm 0.3cbm/min
Overall Dimension: 2650×1000×2300mm
Hopper Volume: 50L(Main) 35L (Assist)
---------------------------------------------------------------------
