產品規格



1) Dimension: a)51*20*15mm b)58*30*28mm c) 60*45*15mm d)75*38*25mm e)75*39.5*30mm f)94*56.5*33mm g) 120*60*32mm 2) Rated voltage: 5V/12V/24V 3) Type: ball bearing, sleeve bearing 4) Safety Approvals: CE, TUV, UL, CUL, CCC 5) Electric strength: 1mAmax at 1000VAC for 1 min between lead wire and frame. 6) Insulation resistance: 10M ohm between lead wire and frame (DC 500V) 7) Life expectancy (ball bearing):50,000hrs rain at 25 degree C relative humidity 65%+/-20% 8)Life expectancy(sleeve bearing):＞30,000hrs rain at 25 degree C relative humidity 65%+/-20% 9)Operation temperature:-10 to 70℃ 10)Storage temperature:-40 to 75℃ 11) Lead Wire: UL1007 (AWG18-30) 12) Protection: Motor protection and polarity protection 13) Plastic Material: Black PBT (UL 94v-0) glass filled 14) Frame: Plastic Impeller: Plastic 15) Function: Function type is optional
