1.型號 Model

CJ-R5

2.木芯直徑 Log Kayu Diameter (max.最大)

32 cm

3.廢木芯直徑 Center Core (min.最小)

35 mm

4.木長(刀長) Log (Knife) Length

1397 mm

5.單板厚度 Veneer Thickness

0.8 – 4.0 mm

6.旋切速度 Lathe Speed

31 M/min

7.總電力 Total Power

＊SERVO MOTOR:7.5KW*1

＊ROLLER MOTOR:11KW*2

＊CONVOYOR MOTOR:0.75KW

30 kw

8.總重量 Total Weight

4800 kgs

9.裝櫃尺寸 Container Size (呎ft)

10.9 x 6.5

10.裝箱尺寸 Packing Size :10.53L*5.86W*3.14H(呎ft)
