hydraulic scrap metal baler /baling machine
產品型號:Y81-630
產品分類:包裝印刷暨食品及製藥機械 / 包裝機械 / 可回收或環保材料/製品
產品特色
1 fluid drive system
2 smart design & solid structure
3 handy operation panel
4 various types 63-400T
5 customize service
產品規格
1,Brief discribe Machine model:
The machine has fluid drive system, smart design & solid structure, handy operation panel. The types of machine is from 63 tons to 400tons.
2,Application:
Titan® Machinery,Y81 series hydraulic metal balers (baling machine/compressor) are mainly used in steel manufacture, recycling companies, ferrous & non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles) into required shapes (cuboid, cylindrical, octagon etc.), so as to reduce the transportation cost, to increase the speed of furnace feeding and reduce the furnace loss.
3, Features:
a) Hydraulic drive system, manual valve control or PLC control.
b) Bale-discharging method: "turn-out"; "push-out" (forward or side push); manual discharging.
c) No footing bolts needed in installation; diesel engine can be equipped for power.
d) Various types to choose with baling force from 63 to 400 tons; productivity from 4 to 40 tons per shift (8 hours standard)
4, Technical parameters:
Nominal force: |
630 (KN) |
Bale size: |
200*200 (mm) |
Bale density: |
≥ 1.8 t/m3 |
Bale discharging: |
Turn over & pust out optional |
Stuffing room(L*W*H): |
1000*600*500 (mm) |
Production(per 8 hours): |
4-6 tons |
Cycle time: |
75 (s) single cycle |
Power: |
7.5 KW |
Nominal pressure: |
21 Mpa |
Operation: |
Manual/Automatic |
4, ISO, CE approved
5, Warranty and after-sale service:
1) 12 months quality guarantee after installation
2) life long technical support and spare parts supply
3) 24 hours on line customer service
