Isobaric pressure filling machine with double heads
產品型號：Isobaric pressure filling machine with double head
產品分類：包裝印刷暨食品及製藥機械 / 包裝機械 / 飲料包裝機
產品特色
3. The main component: machine frame, beer storage canister, beer filling valve, vacuum system, air-drove jack-up system
4. Features: The main material is stainless steel, all the surface is polished, easy to operate and clean.
產品規格
1. Specification
Model: GZ06
Size of plate form: 600mm*500mm
Height of the plat form: 600mm
Size of the machine: 600mm*500mm*1600mm
Weight: 100kg
Production capacity: 300-500 bottles per hour
2. Technology specification
Pressure of the beer: 0.15-0.2Mpa
Pressure of the air: 0.4-0.6Mpa
Pressure of the CO2: 0.15-0.2 Mpa
Pressure of the cylinder: 0.3-0.4Mpa
Voltage of the electricity: 220V
