產品規格

Two-stage speed shifting vortex gearcase
Transmission Type:Automatic Centrifugal
Transmission Ratio:35:1
Boring Roting Speed (rpm):180-210rpm
Boring Rotate Direction:clockwise
Weight(Without drill bit) :11.00kg
Dimension (L x W x H):61*39*29cm
Engine Model:GXH50
Displacement (CC):49.5CC
Max Power (kw/r/min):2.3hp/7000rpm
Max Torque (N.m/r/min):2.45
Max Horsepower(PS):2.3HP
Starting System:Re-coil
Cooling System:Air-cool
Ignition System:C.D.I
Spark Plug: L7T
Fuel Tank Capacity (L):1.2
Drill Bit Dimension:Height: 76cm/100mm
Diameter: 80,100,150,200,250,300mm
Package Weight:12.5Kgs
